We are one of the main suppliers of EN40B nitriding steel, delivering it to the different parts of the country.
EN40B is a chromium molybdenum steel generally supplied in the solidified and tempered "T" condition, which offers high wear imperviousness together with great toughness and ductility.
EN40B in T condition has a tensile of 850-1000 N/mm². It is described by its reasonableness for nitriding, which can give a hard wear resistant case in the scope of 61-65Rc. The generally low temperature of the nitriding process produces EN40B segments with a scale free surface, with minimum distortion during the warmth treatment process.
EN40B might be utilized as a part of its supply condition (normally 'T') for applications and segments which require a high tensile steel quality and high creep quality at temperatures up to 600°C.
Element | Min | Max |
|---|---|---|
| Carbon, C | 0.20 | 0.30% |
| Manganese, Mn | 0.40 | 0.65% |
| Silicon, Si | 0.10 | 0.35% |
| Nickel, Ni | -.-- | 0.40% |
| Molybdenum, Mo | 0.40 | 0.70% |
| Chromium,Cr | 2.90 | 3.50% |
| Sulfur, S | -.-- | 0.05% |
| Phosphorous, P | -.-- | 0.05% |
Condition | Tensile N/mm² | Yield N/mm² | Elongation % | Izod KCV J | Hardness Brinell |
|---|---|---|---|---|---|
| U | 925-1075 | 755 | 12 | 42 | 269-331 |
| T | 850-1000 | 680 | 13 | 50 | 248-302 |
| S | 775-925 | 585 | 15 | 50 | 223-277 |
